Qingdao KXD Steel Structure Co., Ltd kxdandy@chinasteelstructure.cn 86--13853233236
製品詳細
起源の場所: チンダオ,中国
ブランド名: KXD
証明: CE, ISO, SGS
モデル番号: S-0084
支払及び船積みの言葉
最小注文数量: 500平方メートル
価格: US$ 50-80 per square meter
パッケージの詳細: 鋼パネルのための散装,鋼構造のための鋼パレット,小型設置用アクセサリーのための木箱
受渡し時間: 30~40 営業日
支払条件: L/C、T/T
供給の能力: 月3千トン
設置: |
無料 設置図の詳細 & オンライン・テクニカルガイド |
プレハブ: |
作業場外で 直接設置可能 |
接続: |
高強度ボルト接続 |
訪問: |
ワークショップ訪問と品質チェックは許容範囲内です |
ターンキー プロジェクト: |
受け入れられる |
デザイン: |
建築設計の自由とカスタム |
寸法: |
顧客 の 要求 |
ドア: |
スライドドアやロールアップドア |
色: |
顧客からの要求 |
表面: |
熱浸しでガルバン化/塗装 |
フレーム: |
鋼鉄構造 |
生涯: |
50年以上 |
構造型: |
高強度鋼筋構造枠 |
第三者テスト: |
SGS、BV |
設置: |
無料 設置図の詳細 & オンライン・テクニカルガイド |
プレハブ: |
作業場外で 直接設置可能 |
接続: |
高強度ボルト接続 |
訪問: |
ワークショップ訪問と品質チェックは許容範囲内です |
ターンキー プロジェクト: |
受け入れられる |
デザイン: |
建築設計の自由とカスタム |
寸法: |
顧客 の 要求 |
ドア: |
スライドドアやロールアップドア |
色: |
顧客からの要求 |
表面: |
熱浸しでガルバン化/塗装 |
フレーム: |
鋼鉄構造 |
生涯: |
50年以上 |
構造型: |
高強度鋼筋構造枠 |
第三者テスト: |
SGS、BV |
| Attribute | Value |
|---|---|
| Installation | Free Installing drawing details & Quick on-line technical guide |
| Prefabrication | Off-site in workshop & Ready for direct installation |
| Connection | High Strength Bolt connection |
| Visit | Workshop Visit And Quality Check Acceptable |
| Turnkey Project | Acceptable |
| Design | Custom with Free Architectural design |
| Dimensions | Customers' Requirement |
| Door | Sliding door or rolling up door |
| Color | Client's Request |
| Surface | Hot-dip Galvanized / Painted |
| Frame | Steel structure |
| Lifetime | over 50 years |
| Structure Type | High Strength Steel Structure Frame |
| Third Party Test | SGS, BV, ITS |
| Component | Materials | Specifications |
|---|---|---|
| Steel Frame | Q355B (equivalent to S355JR, ASTM A572 Gr. 50) Q235B (equivalent to S235JR, ASTM A36) |
H section steel Steel plate thickness: 8-30mm |
| Welding | Automatic submerged arc welding | |
| Rust removal | Sand blasting | |
| Surface finish | Alkyd / Epoxy zinc paint / hot dipping galvanized | |
| Connection | By High strength bolt, Grade 10.9, Grade 8.8 | |
| Supporting System | Angle steel brace | L steel, Q235B, painted / hot dipping galvanized |
| Horizontal brace | Steel bar, Q235B, painted / hot dipping galvanized | |
| Column brace | Steel bar, Q235B, painted / hot dipping galvanized | |
| Tie beam | CHS, Q235B, painted / hot dipping galvanized | |
| Connection | By ordinary bolt, Grade 4.8 | |
| Roof | Purlin | C/Z purlin, Q235B, pre-galvanized 100g-275g |
| Roof panel | Insulated sandwich panel or Corrugated steel sheet | |
| Edge cover | steel sheet trimming | |
| Gutter | Stainless steel / Galvanized sheet | |
| Down pipe | Φ110 PVC-U, Φ150 PVC-U | |
| Fix Accessories | sealing, self-tapping screws, etc. | |
| Walls | Purlin | C/Z purlin, Q235B, pre-galvanized 100g-275g |
| Wall | Insulated sandwich panel or corrugated steel sheet | |
| Accessories | sealing, self-tapping screws, etc. | |
| Edge cover | steel sheet trimming | |
| Fix Accessories | sealing, self-tapping screws, etc. | |
| Door and window | Different sizes and types are possible to custom. | |
| Additional option | Skylight panel; Roof ventilator; Parapet; Glass curtain wall; Decorative aluminum panel | |
| Buildings' Structure Type | Non-production processing building | Production processing building | Corrosive Production processing building |
|---|---|---|---|
| Steel structure | 80 years | 70 years | 50 years |
| Reinforced Concrete structure | 60 years | 50 years | 35 years |
| Brick Concrete structure | 50 years | 40 years | 30 years |
| Wood and Brick structure | 40 years | 30 years | 20 years |
| Simple structure | 5-10 years | ||
| Our Service | Details |
|---|---|
| Design |
Large engineer team for quick response and quick quote Capability for elaborate design, high wind resistance performance Architecture Grade: I architect certificate |
| Manufacture | We can manufacture all kinds of steel structure products based on different conditions of projects. |
| Workshop visit & Production Check |
Always warmly welcome to visit our production lines before the order Project processing during the production Finished steel components in the packing and loading |
| Certification and Test | We accept your stage to supervise the whole fabrication, steel raw material testing, and also support third-party inspection. |
| Installation |
We provide detailed drawings to ensure installation We also provide remote guidance for installation We can also send a team of engineers to guide or install on site |
| Quality inspection |
Factory Self-inspection Customer inspection Third party inspection |
Architectural design to meet the required loads.
Minimum Order Quantity: 500sqm
Normally for steel structure, we will pack them by the steel pallet. Packed processing outside of the loading container is easier to operate, easier to adjust and more efficient to use the container limited space. At the same time, steel pallet will also protect steel components to reduce the conflicts and surface coating abrasion.
The steel pallet will be loaded by closed containers, like 20'GP, 40'HC.
If clients wants to save the steel pallet cost, the steel components is better to be loaded into open top container one by one, like 40'OT.
Closed container:
Advantage: Cheaper shipping cost, all members be packed together and reduce friction, the surface coating of steel members will be much better protected; easy unload
Disadvantage: steel pallet cost
Open top container:
Advantage: easy to load & unload; save steel pallet cost
Disadvantage: higher shipping cost, a leak and few quantity to load
KXD is on-line for your any questions! Feel free to contact for your project! We will offer free architecture design for you.
